03Model Range
Model Range
The Dynapack is a modular design which allows you to upgrade to a 4WD system at a later date. Any of the 2WD models can be combined together to make your 4WD system.
2WD Hub Dyno's
3 models| Model | HP | kW | lb/ft | Nm | Hub Speed |
|---|---|---|---|---|---|
| DAQ3 | 1031 | 769 | 2212 | 3000 | 2450 |
| DAQ4 | 1375 | 1026 | 2950 | 4000 | 2450 |
| DAQ5 | 1547 | 1154 | 3319 | 4500 | 2450 |
4WD Hub Dyno's
6 models| Model | HP | kW | lb/ft | Nm | Hub Speed |
|---|---|---|---|---|---|
| DAQ33 | 2063 | 1539 | 4424 | 6000 | 2450 |
| DAQ43 | 2408 | 1796 | 5162 | 7000 | 2450 |
| DAQ44 | 2757 | 2052 | 5900 | 8000 | 2450 |
| DAQ53 | 2580 | 1924 | 5531 | 7500 | 2450 |
| DAQ54 | 2924 | 2181 | 6269 | 8500 | 2450 |
| DAQ55 | 3096 | 2309 | 6638 | 9000 | 2450 |
Motorbike Solutions
Motorbike Solutions
Dynapack™ also has solutions for motorbikes. Whether it’s for R&D, race tuning or diagnostics, it can be done in house with reliability, safety and accuracy.
The new Dynapack SP1000CD chain drive dyno has been specifically designed for race teams and R&D departments.
(* Image below is representative of current production design at time of publication).
